The PA-01 Mini Linear Actuator is a compact electric linear actuator designed for applications requiring medium force, low current draw, and flexible stroke options. Available in 12 VDC and 24 VDC configurations with stroke lengths ranging from 1" to 40", the PA-01 combines a Grade 45 steel stroke rod, aluminum alloy housing, and IP65 ingress protection for dependable operation in environments exposed to dust and water. A standard 2-Pin Molex Mini-Fit Jr. connector supports straightforward integration, while optional 6-Pin Potentiometer and Hall sensor feedback models are available for applications requiring position feedback.
The PA-01 Mini Linear Actuator balances compact size, medium-force capabilities, and low current draw, making it suitable for applications where installation space and power efficiency are important. Multiple force, speed, current, and stroke configurations allow you to select the model that best fits your application. Common uses include food and beverage equipment, home automation, general automation, and medical equipment.
*Product housing may vary from the images based on available inventory for the selected force and stroke length at the time of order.
Actuators Comparison Chart
The PA-01 Mini Linear Actuator is designed for straightforward integration into new and existing systems. Its compact footprint, standardized electrical connection, multiple stroke options, and IP65-rated construction support flexible installation across a wide range of automation projects. Refer to the Product Specifications table for dimensions, duty cycle, environmental rating, connector type, materials, stroke range, and other technical specifications.
Complete your PA-01 Mini Linear Actuator system with compatible mounting brackets, gas springs, and control components. Refer to the compatibility tables to identify accessories suitable for your selected actuator voltage, connector type, and feedback configuration.
MOUNTING BRACKETS:
The PA-01 Mini Linear Actuator is compatible with the BRK-14, BRK-01-U, BRK-21, and BRK-22 mounting brackets. These options support different mounting requirements and installation configurations. Refer to the Brackets Compatibility table and corresponding product pages to select the appropriate mounting bracket for your application.
GAS SPRING OPTIONS:
The GS-01 gas spring can be paired with the BRK-14 mounting bracket to provide additional support alongside the PA-01 Mini Linear Actuator in upward load applications.
CONTROL SYSTEMS:
The PA-01 Mini Linear Actuator is compatible with a range of Progressive Automations control systems. Its low current draw supports straightforward integration with compatible control boxes. Refer to the compatibility tables to select the appropriate controller and supporting components based on actuator voltage, connector type, current requirements, and feedback configuration. For additional options, visit our control systems page.
Custom options
Looking for an actuator but the specifications don't exactly match what you require? We have an extensive list of customization capabilities to ensure you get exactly what you need for your project. Download this product's data sheet and find out more about your customization options!
The PA-01 Mini Linear Actuator is a compact electric linear actuator designed for applications requiring medium force, low current draw, and flexible stroke options. Available in 12 VDC and 24 VDC configurations with stroke lengths ranging from 1" to 40", the PA-01 combines a Grade 45 steel stroke rod, aluminum alloy housing, and IP65 ingress protection for dependable operation in environments exposed to dust and water. A standard 2-Pin Molex Mini-Fit Jr. connector supports straightforward integration, while optional 6-Pin Potentiometer and Hall sensor feedback models are available for applications requiring position feedback.
The PA-01 Mini Linear Actuator balances compact size, medium-force capabilities, and low current draw, making it suitable for applications where installation space and power efficiency are important. Multiple force, speed, current, and stroke configurations allow you to select the model that best fits your application. Common uses include food and beverage equipment, home automation, general automation, and medical equipment.
*Product housing may vary from the images based on available inventory for the selected force and stroke length at the time of order.
Actuators Comparison Chart
The PA-01 Mini Linear Actuator is designed for straightforward integration into new and existing systems. Its compact footprint, standardized electrical connection, multiple stroke options, and IP65-rated construction support flexible installation across a wide range of automation projects. Refer to the Product Specifications table for dimensions, duty cycle, environmental rating, connector type, materials, stroke range, and other technical specifications.
Complete your PA-01 Mini Linear Actuator system with compatible mounting brackets, gas springs, and control components. Refer to the compatibility tables to identify accessories suitable for your selected actuator voltage, connector type, and feedback configuration.
MOUNTING BRACKETS:
The PA-01 Mini Linear Actuator is compatible with the BRK-14, BRK-01-U, BRK-21, and BRK-22 mounting brackets. These options support different mounting requirements and installation configurations. Refer to the Brackets Compatibility table and corresponding product pages to select the appropriate mounting bracket for your application.
GAS SPRING OPTIONS:
The GS-01 gas spring can be paired with the BRK-14 mounting bracket to provide additional support alongside the PA-01 Mini Linear Actuator in upward load applications.
CONTROL SYSTEMS:
The PA-01 Mini Linear Actuator is compatible with a range of Progressive Automations control systems. Its low current draw supports straightforward integration with compatible control boxes. Refer to the compatibility tables to select the appropriate controller and supporting components based on actuator voltage, connector type, current requirements, and feedback configuration. For additional options, visit our control systems page.
Custom options
Looking for an actuator but the specifications don't exactly match what you require? We have an extensive list of customization capabilities to ensure you get exactly what you need for your project. Download this product's data sheet and find out more about your customization options!
Depending on your application, there are different specification requirements you should consider when determining the linear actuator you need. These requirements include force, stroke, speed and mounting dimensions. For detailed actuator information, you can refer to either the datasheet or the specification table located on the selected actuator's product page. You can also contact us to speak with one of our expert engineers.
Duty cycle is the fraction of the working period in which a linear actuator can remain active. You can calculate the duty cycle of a linear actuator by using the following equation: Duty cycle (%) = (Time the linear actuator is active) / (Time for one working period)
For example: With a 25% duty cycle, an actuator can run for 5 minutes continuously before needing to rest for 15 minutes before operating.
Stroke is the travel distance of the extending rod. To find the stroke length you require, measure your application from the fully retracted position to the fully extended position. The difference will equal the stroke length you require.
We always recommend purchasing an actuator with a higher force rating than what the application requires. If unsure of your force requirements, this article may help you calculate this: How to Calculate Force to Find the Right Linear Actuator
Yes, this is possible. However, it does depend on the units you are currently using. To synchronize actuators, they require a form of feedback such as a potentiometer or hall effect sensors. For more information, see below some of our key content regarding linear actuator synchronization.
The control box you choose should be able to provide sufficient voltage and current rating to your actuator. If you are unsure of the specifications, please contact us.
Alternatively, you can also find compatible control boxes on your selected linear actuator's product page.
Backdriving is when an actuator starts sliding down under load, when it is either overloaded or when the actuator has been damaged. Watch the video.
What Does Dynamic and Static Load Ratings Mean?Dynamic load rating is the amount of weight an actuator can pull or push safely when being powered. Static load rating is the amount of weight the actuator can hold or withstand without back driving when it is not being powered. For example, let's just say you have an actuator installed on a window and the static load rating of the actuator is 100lbs, it could experience backdriving when there is a high wind event, which means there will be more pressure exerted on the actuator which would exceed the 100lbs load rating of the actuator.
What Is Lateral Loading?Lateral loading is when the actuator experiences forces from the lateral plane. Actuators are not meant to handle lateral forces at all so if it experiences any lateral forces, it will likely damage the actuator or bend the rod. So it's advised never to use lateral forces and always make sure the actuator is fully in line or in sync with your application, so it does not take any load other than the axial load. Watch the video.
